Freight elevators are versatile and useful systems that provide vertical movement of heavy loads in industrial and commercial areas. These elevators are especially used in areas that require heavy load transportation, such as warehouses, factories, logistics centers and shopping malls. For a correct freight elevator design and installation, careful planning of freight elevator dimensions is essential.
Factors Affecting Freight Elevator Dimensions
Carrying Capacity: The capacity of freight elevators generally starts from 500 kg and can go up to 10,000 kg or more. Capacity is determined by the type and weight of the loads to be transported.
Cabin Dimensions: Cabin dimensions vary depending on the size and shape of the loads.
A standard freight elevator cabin can generally be between 1.5 m x 1.5 m and 3 m x 4 m.
For larger or specific needs. can be customized.
Door Type and Dimensions: Wide door systems are generally preferred in freight elevators.
Door width: between 1 m and 2.5 m.
Door height: can be between 2 m and 3 m.
Floor Height: The height between floors is a critical factor in freight elevator designs. It is generally designed for floor heights between 0 m and 12 m.
Dimensions of the Well:
The depth of the well is important for the compatibility of the cabin and carrier systems.
Wells are generally 1.5 m to 3 m deep. is required.
Standard Freight Elevator Dimensions
Although freight elevator dimensions vary depending on the area of use, the following general standards are frequently used:
Cabin Dimensions According to Capacity:
- 1000 kg: 1.5 m x 2 m x 2.2 m
- 2000 kg: 2 m x 2.5 m x 2.4 m
- 3000 kg: 2.5 m Door: 1.5 m should be determined.
Layout Planning: The elevator shaft and the machine room must be suitable for the existing building structure.
Safety Standards: Freight elevators must comply with national and international standards such as TSE and EN 81-20.
Energy Efficiency: Systems that consume less energy are preferred. should be done.
Ease of Maintenance: Designs that offer ease of periodic maintenance reduce costs in the long term.
Freight elevator dimensions are of critical importance for a correct design and application. As OHC Lift, we prioritize both efficiency and safety by offering solutions tailored to your needs. You can examine our special freight elevator designs by contacting our professional team contact. For information about prices, you can read our article freight elevator prices.
